Ripples in Mathematics

Produktbeschreibung

Yet another book on wavelets. There are many books on wavelets available, written for readers with different backgrounds. But the topic is becoming ever more important in mainstream signal processing, since the new JPEG2000 standard is based on wavelet techniques. Wavelet techniques are also impor tant in the MPEG-4 standard. So we thought that there might be room for yet another book on wavelets. This one is limited in scope, since it only covers the discrete wavelet trans form, which is central in modern digital signal processing. The presentation is based on the lifting technique discovered by W. Sweldens in 1994. Due to a result by I. Daubechies and W. Sweldens from 1996 this approach covers the same class of discrete wavelet transforms as the one based on two channel filter banks with perfect reconstruction. The goal of this book is to enable readers, with modest backgrounds in mathematics, signal analysis, and programming, to understand wavelet based techniques in signal analysis, and perhaps to enable them to apply such methods to real world problems. The book started as a set of lecture notes, written in Danish, for a group of teachers of signal analysis at Danish Engineering Colleges. The material has also been presented to groups of engineers working in industry, and used in mathematics courses at Aalborg University.

Inhaltsverzeichnis

1. Introduction.- 1.1 Prerequisites.- 1.2 Guide to the Book.- 1.3 Background Information.- 2. A First Example.- 2.1 The Example.- 2.2 Generalizations.- Exercises.- 3. The Discrete Wavelet Transform via Lifting.- 3.1 The First Example Again.- 3.2 Definition of Lifting.- 3.3 A Second Example.- 3.4 Lifting in General.- 3.5 DWT in General.- 3.6 Further Examples.- Exercises.- 4. Analysis of Synthetic Signals.- 4.1 The Haar Transform.- 4.2 The CDF(2,2) Transform.- Exercises.- 5. Interpretation.- 5.1 The First Example.- 5.2 Further Results on the Haar Transform.- 5.3 Interpretation of General DWT.- Exercises.- 6. Two Dimensional Transforms.- 6.1 One Scale DWT in Two Dimensions.- 6.2 Interpretation and Examples.- 6.3 A 2D Transform Based on Lifting.- Exercises.- 7. Lifting and Filters I.- 7.1 Fourier Series and the z-Transform.- 7.2 Lifting in the z-Transform Representation.- 7.3 Two Channel Filter Banks.- 7.4 Orthonormal and Biorthogonal Bases.- 7.5 Two Channel Filter Banks in the Time Domain.- 7.6 Summary of Results on Lifting and Filters.- 7.7 Properties of Orthogonal Filters.- 7.8 Some Examples.- Exercises.- 8. Wavelet Packets.- 8.1 From Wavelets to Wavelet Packets.- 8.2 Choice of Basis.- 8.3 Cost Functions.- Exercises.- 9. The Time-Frequency Plane.- 9.1 Sampling and Frequency Contents.- 9.2 Definition of the Time-Frequency Plane.- 9.3 Wavelet Packets and Frequency Contents.- 9.4 More about Time-Frequency Planes.- 9.5 More Fourier Analysis. The Spectrogram.- Exercises.- 10. Finite Signals.- 10.1 The Extent of the Boundary Problem.- 10.2 DWT in Matrix Form.- 10.3 Gram-Schmidt Boundary Filters.- 10.4 Periodization.- 10.5 Moment Preserving Boundary Filters.- Exercises.- 11. Implementation.- 11.1 Introduction to Software.- 11.2 Implementing the Haar Transform Through Lifting.- 11.3 Implementing the DWT Through Lifting.- 11.4 The Real Time Method.- 11.5 Filter Bank Implementation.- 11.6 Construction of Boundary Filters.- 11.7 Wavelet Packet Decomposition.- 11.8 Wavelet Packet Bases.- 11.9 Cost Functions.- Exercises.- 12. Lifting and Filters II.- 12.1 The Three Basic Representations.- 12.2 From Matrix to Equation Form.- 12.3 From Equation to Filter Form.- 12.4 From Filters to Lifting Steps.- 12.5 Factoring Daubechies 4 into Lifting Steps.- 12.6 Factorizing Coiflet 12 into Lifting Steps.- Exercises.- 13. Wavelets in Matlab.- 13.1 Multiresolution Analysis.- 13.2 Frequency Properties of the Wavelet Transform.- 13.3 Wavelet Packets Used for Denoising.- 13.4 Best Basis Algorithm.- 13.5 Some Commands in Uvi_Wave.- Exercises.- 14. Applications and Outlook.- 14.1 Applications.- 14.2 Outlook.- 14.3 Some Web Sites.- References.
